We can also offer the FINISHED PRODUCTS for kinds of special profiles according to customers’ drawings, such as:

1. fireproof and heat insulation door and window partition

2. fireproof curtain wall according to customers’ drawings

3. Photovoltaic Solar support

Features

C/Z purlin interchangeable rollformer can produce C, Z profiles. Produce the C and Z purlin by exchange one side of the roller up and down, only need about half hour. This machine also can adjust roller horizontal distance to achieve C or Z purlins of the width with high precision automatic. And also save time and increase production.

Application

The finished products are widely used as the supporter of roof and wall in large-scale and mid-scale construction, such as factory, warehouse, garage, exhibition center, cinema, theatre, garden and so on.

Process Flow

Uncoiler --- Feeding --- Straightening --- Pre-punching --- Pre-cutting --- Roll Forming --- Exit Rack

Machine Configurations

1.      Hydraulic Uncoiler

2.      Feeding Device

3.      Straightening

4.      Roll Forming Machine

5.      Post Punching

6.      Post Cutting

7.      PLC Control System

8.      Exit Rack

•

  Roll Forming Machine

•

  Sample 2

•

  Sample 3
