1. The main machine adopts QC11Y series

(1) All steel welded mono-block construction

(2) Light line device for easy cut

(3) Adjustable cutting angle by hydraulic valve

(4) Ball worktable for easy feeding

(5) Front guard to ensure the operation safety

(6) Quick blade clearance adjusted by manual with indication

(7) Back gauge stroke adjusted by motor which located in the end of the synchronized shaft for precise working and low noise

(8) E10 DRO display back gauge stroke, cutting times

(9) Standard front support sheet frame

2. The back gauge equipped with ball screw & servo motor

3. Economic CNC systems (E200) control back gauge stroke, cutting times
